Installation

Set-Top Boxes

The STB-02SB (FG3100-61), STB-03CC (FG3100-62), and STB-04 (FG3100-65) Set-Top Boxes support
viewing live programming via a producer channel or an MPEG encoder. The set-top boxes access your Vision
server and display available programming on a connected video source. The set-top boxes are used only for
MPEG content. They support viewing MPEG Video on Demand, but support only Stop, Play, Pause, Fast
Forward, and Rewind features.
FIG. 24 displays the rear panel of the STB-02SB Set-Top box.
FIG. 24 STB-02CC Set-Top Box (rear-view)
The Set-Top Boxes have a limit of 18Mbps. Heavy traffic loads can cause the set-top
box to reset itself periodically.
FIG. 25 displays the rear panel of the STB-04 Set-Top box.
FIG. 25 STB-04 Set-Top Box (rear-view)
