Perform these steps to configure the VBrick WMV multicast stream:
1.
Select Configure Encoder from the Encoder menu. The Live Service page opens (FIG. 68).
2.
Use the Video Input options menu to indicate whether you are connecting to the S-video, component, or
composite port on the encoder.
3.
Use the Video Standard options menu to indicate which video standard the encoder is using.
4.
Use the Aspect Ratio options menu to indicate the aspect ratio you want to use for the multicast stream.
5.
Use the Audio Input options menu to indicate whether you are connecting to the 3.5 mm jack or the Mic
DIN.
6.
Use the Encoder Profile options menu to indicate which profile the encoder is using.
7.
Use the Video Resolution options menu to indicate the video resolution of the multicast stream.
8.
Use the Video Bitrate options menu to indicate the video bitrate of the multicast stream.
9.
Use the Video Mode options menu to indicate the video mode of the multicast stream. It is recommended
that you select CBR.
10.
Use the Audio Bitrate options menu to indicate the audio bitrate of the multicast stream.
11.
Use the Audio Sample Rate options menu to indicate the audio sample rate of the multicast stream.
12.
Click Apply. Clicking Apply saves your configuration.
13.
Click the Enable check box to begin the multicast stream.

Viewing the Stream

The Vision
a user player. Click the View Stream option in the Services menu to view the stream. You must select
Encoder Enable on the configuration page to view the stream.
FIG. 72
View Unicast Stream
2
Vision Operation/Reference Guide
2
Services manager provides a menu option to allow you to view the stream without having to start
