Scheduled Recording; Event Log - AMX Vision 2 Operation/Reference Manual

Record Service

Scheduled Recording

The Scheduled Record feature allows you to schedule when a live service is to be recorded. You must select
the source from which to record and enable the service before editing the schedule. Scheduled recordings are
only supported in the Live MPEG service and in 10 minute increments.
1.
Select Configure DVR from the Record Services menu on the left pane of the window. The Record
Service page appears (FIG. 111).
FIG. 111 Scheduled Recording screen
2.
In the Schedule editor, select the time where the recording should occur. A pop-up dialog box appears
(FIG. 112).
FIG. 112 Scheduled Recording dialog box
3.
Enter the name the recording in the Program Name field.
4.
Use the up-and-down arrows to indicate the duration of the recording in 10 minute increments.
You can enter a value in the Duration field, however, Vision
recordings in 10 minute increments. If you enter a value in the Duration field that isn't
a 10 minute increment, Vision
increment without alerting you.
5.
Click Save.

Event Log

In common with other services, the Record service generates an event log which you can examine by selecting
View Event Log from the Record services menu.
116
2
automatically rounds up to the next 10 minute
2
only supports scheduled
2
Vision Operation/Reference Guide
