Margins; Output - AMX Vision 2 Operation/Reference Manual

Margins

The Configure Margins screen enables you to adjust the position of the images on your display. Use the up and
down cursor buttons on the remote control to select an option. Use the left and right cursor buttons to change
the setting of the selected margin. The image on the screen moves as you increase or decrease the value of an
individual margin, so you can see the results of your adjustments as you make them. Press the OK button to
apply the new setting.
FIG. 36 Configure Margins screen
Rebooting your set-top box can cause your margin settings to be reset.

Output

The Configure Output screen enables you to change the following display options: TV standard, resolution,
aspect radio, and connection type.
FIG. 37 Configure Output screen
