use both stranded or solid wire but the requirements are different.
The use of stranded wire with a conductor section values between 1.5 - 4 mm² are only allowed
with the mandatory use of properly crimped ferrules.
X
Y
connector respecting the indications printed on each of the three con-
nection terminals (tightening torque 0.8...1Nm)
ening torque (4+1Nm) in order to guarantee the IP65 protection level
Y
30mm
L,N 25 mm
N
L
Max 6 mm²
Ø10÷14mm
2
1
- 76 -
5 - Installation
X
12mm with ferrules*
8mm without ferrules*
z:
z
10mm max
-
