Operating Diagram - ABB REACT 2 Series Product Manual

O
perating diagram
New installation
REACT 2 is perfect for new installation because it is a PV inverter with
an integrated battery allowing simpler installation and best performances
REACT 2
REACT 2 can be installed together with an existing PV inverter on AC
side of the home grid, functioning as battery manager only
Existing
solar inverter
RS-485
Meter
House
REACT 2
RS-485
Meter
House
- 38 -
2 - Characteristics
Utility
Grid
meter
DC line
AC line
Utility
Grid
meter
DC line
AC line
