I-2-2 Wall-Mounted Installation

I-2-2 Wall-Mounted Installation
Vigor2762 has keyhole type mounting slots on the underside.
1. A template is provided on the Vigor2762 packaging box to enable you to space the
screws correctly on the wall.
2. Place the template on the wall and drill the holes according to the recommended
instruction.
3. Fit screws into the wall using the appropriate type of wall plug.
Note
4. When you finished about procedure, the router has been mounted on the wall firmly.

I-2-3 Installing USB Printer to Vigor Router

I-2-3 Installing USB Printer to Vigor Router
You can install a printer onto the router for sharing printing. All the PCs connected this
router can print documents via the router. The example provided here is made based on
Windows 7. For other Windows system, please visit www.DrayTek.com.
6
The recommended drill diameter shall be 6.5mm (1/4").
