Intended Use; Proper Environment - MICRO-EPSILON capaNCDT 6200 Operating Instructions Manual

Safety
1.4
- The capaNCDT 6200 measuring system is designed for use in industrial areas. It is used for
- The system must only be operated within the limits specified in the technical data, see Chap. 2.3.
1.5
- Protection class:
- Operating temperature:
- Humidity:
- Ambient pressure:
- Storage temperature:
- The space between the sensor surface and the target must have an unvarying dielectric constant.
- The space between the sensor surface and the target may not be contaminated (for example water,
1) An operating temperature of -50 ... +100 °C (-58 to +212 °F) applies for the sensors CSG0.50-CA and
CSG1.00-CA -50
2) A storage temperature of -50 ... +100 °C (-58 to +212 °F) applies for the sensors CSG0.50-CA and
CSG1.00-CA -50
capaNCDT 6200

Intended Use

ƒ displacement, distance, thickness and movement measurement
ƒ position measuring of parts or machine components
The system must be used in such a way that no persons are endangered or machines and other mate-
rial goods are damaged in the event of malfunction or total failure of the system.
Take additional precautions for safety and damage prevention in case of safety-related applications.

Proper Environment

ƒ Sensor:
ƒ Sensor cable:
ƒ Controller:
ƒ Sensor:
ƒ Sensor cable:
ƒ Controller:
rubbed-off parts, dust, etc.)
IP 40
-50 ... +200 °C (-58 to +392 °F)
-100 ... +200 C (-58 to +392 °F) (CCmx and CCmx/90)
-20 ... +80 °C (-58 to +392 °F) (CCgx and CCgx/90 - permanently)
-20 ... +100 °C (-58 to +392 °F) (CCgx and CCgx/90 - 10,000 h)
+10 ... +60 °C (+50 to +140 °F)
5 - 95 % (non-condensing)
Atmospheric pressure
-50 ... +200 °C (-58 to +392 °F)
-50 ... +200 °C (-58 to +392 °F) (CCmx and CCmx/90)
-50 ... +80 °C (-58 to +176 °F) (CCgx and CCgx/90)
-10 ... +75 °C (+14 to +167 °F)
1
2
Page 9
