Appendix| Accessories, Service
Mounting plate
Plugging off assistance for con-
nector
Dimensions in mm (inches), not to scale
Further more, the conversion kit contains sleeve nuts, threaded rods in different lengths and screws.
capaNCDT 6200
3
(.12)
10
0.7
(.39)
(.03)
20
(.79)
Aluminum /
powder-coated
Page 87
