Ethernet Interface
6.5.5
This function enables the scaling of a measuring channel and the mathematical combination of individual
channels.
Formula: Data channel = Offset + factor measuring channel 1 + factor measuring channel 2 + factor
measuring channel 3 + factor measuring channel 4.
Data channel = digital values
Measuring channel = analog value of a demodulator module
Data channel
6.5.6
This menu item determines the trigger behavior. The triggering is released by an external electrical signal, see
Chap.
If the trigger mode is turned off, the capaNCDT 6200 will send the measuring values without interruption and
with the adjusted data rate.
Trigger mode
6.5.7
Data Rate
capaNCDT 6200
Math Functions
1 / 2 / 3 / 4
Trigger Mode
4.7.2
or by the command $ GMD, see Chap. 6.4.3.
Rising edge
High level
Gate rising edge
Off
Data Rate
2.6 / 5.21 / 10.42 / 15.63 / 26.04 / 31.25 / 52.08 / 62.5 /
104.2 / 520.83 / 1041.67 / 2083.33 / 3906.25 Sa/s
Offset
Factor measuring channel Value
A measuring value is output per edge.
Level triggering. Measuring value output, as long as the level is active.
Starts resp. stops the measuring value output alternatively.
Controller sends measuring values continuously.
Value
Value range ±8-point MR max.
Value range -9,9 ... +9,9
Instructs the sensor about the
frequency, with which data are
output via the Ethernet interface.
