Installation and Assembly
Dimensions in mm (inches), not to scale
Model
CCmxC
CCmxC/90
CCmxB
CCmxB/90
capaNCDT 6200
Sensor cable CCmxC
8.6 (.34) 27 (1.06)
13.7 (.54)
17.5 (.69)
Cable length x
Sensor cable CCmxB
Cable length x
Cable length Cable ø
1.4/2.8 or 4.2 m 2.1 mm
1.4/2.8 or 4.2 m 2.1 mm
1.4/2.8 or 4.2 m 2.1 mm
1.4/2.8 or 4.2 m 2.1 mm
37 (1.46)
27 (1.06)
37 (1.46)
2 axial 1x axial +
connector 1x 90
•
•
Sensor cable CCmxC/90
21 (.83)
Sensor cable CCmxB/90
25 (.98)
Ø7(.28)
For sensors
0
0.05 - 0.8 mm
• 0.05 - 0.8 mm
7 mm
(once)
1 ... 10 mm
• 1 ... 10 mm
Ø6 (.24)
Ø5.4 (.21)
Ø10 (.39)
Min. bending radius
15 mm
(permanently)
