Functional Principle, Technical Data
Demodulator module DL62xx
The demodulator module DL62xx consists of an internal preamplifier, demodulator, output stage and A/D
converter. The internal preamplifier generates the distance dependent measuring signal and amplifies it.
Demodulator and output stage convert the measuring signal in a standardized voltage and current signal.
The measuring values can be processed digitally with the help of the A/D converter.
The trim potentiometer zero allows a special zero adjustment of the analog output signals, see
i
capaNCDT 6200
Output voltage can achieve up to 15 VDC, if the sensor is disconnected respectively exceedance of
measuring range.
Fig. 3.
Page 16
