MICRO-EPSILON capaNCDT 6200 Operating Instructions Manual page 73

Ethernet Interface
Direct connection to PC, controller with static IP (Factory setting)
PC with static IP
Connect the controller to a PC using a direct Ethernet connection (LAN).
Use a LAN cable with RJ-45 connectors for this.
Now start the SensorFinder program. You
will find this program on the provided CD.
Start Scan
Click the button
the designated controller from the list.
In order to change the address settings,
Change IP...
click the button
• Address type: static IP address
• IP address: 169.254.168.150
• Subnet mask: 255.255.0.0
Apply
Click the button
changes to the controller.
Start Browser
Click the button
connect the controller with your default
browser.
1) Requires that the LAN connection on the
PC uses, for example, the following IP ad-
dress: 169.254.168.1.
Interactive web pages for setting the controller and peripherals are now shown in the web browser.
capaNCDT 6200
PC with DHCP
Wait until Windows has estab-
lished a network connection
(Connection with limited con-
. Select
nectivity).
Now start the Sensor-
Finder program. You will
find this program on the
provided CD.
1
Click the button
Scan
to transmit the
nated controller from the
list.
to
Click the button
Browser
controller with your default
browser.
Network
Controller with dynamic IP , PC with DHCP
Connect the controller to a switch using a direct
Ethernet connection (LAN). Use a LAN cable
with RJ-45 connectors for this.
Enter the controller in the DHCP / register the
controller in your IT department.
The controller gets assigned an IP address from your
DHCP server. You can check this IP address with the
SensorFinder program.
Now start the SensorFinder program.
You will find this program on the provided CD.
Click the button
Start
ignated controller from the list.
. Select the desig-
Click the button
the controller with your default browser.
Start
Alternatively: If DHCP is used and the DHCP server is
linked to the DNS server, access to the controller via
to connect the
a host name of the structure "DT6230_<serial_num-
ber>" is possible.
Start a web browser on your PC. To achieve a
controller with the serial number "01234567",
type in the address bar on your browser
"DT6230_01234567".
Start Scan
. Select the des-
Start Browser
to connect
Page 73
