Ethernet Interface
6.4.2
There are three possible settings regarding the trigger input, see Chap. 5.4.
Irrespective of the trigger mode set, a single measured value per channel can be called up by means of
a software command, see Chap. 5.5.3. If the trigger mode is turned off, the capaNCDT 6200 will send the
measurement values without interruption and with the adjusted data rate.
Command
Response
Index
Request Trigger mode
Command
Response
6.4.3
In the trigger mode, one measuring value is transmitted per channel.
Command
Response
capaNCDT 6200

Trigger Mode (TRG)

TRG
$TRGn<CR>
$TRGnOK<CRLF>
n = 0: Continuous transmission (default setting)
n = 1: Triggermode 1 (rising edge)
n = 2: Triggermode 2 (high level)
n = 3: Triggermode 3 (gate rising edge)
? = Request trigger mode
$TRG?<CR>
$TRG?nOK<CRLF>

Get Measured Data (GMD)

GMD
$GMD<CR>
$GMDOK<CRLF> + Measuring value in binary mode (format as in
operating mode "continuous transmission") via data port
