Sensor Cable - MICRO-EPSILON capaNCDT 6200 Operating Instructions Manual

Installation and Assembly
CSG0.50-CAm2.0 and CSG1.00-CAm2.0
Sensor structures
CSG0,50-CAm2,0
Dimensions in mm (inches), not to scale
4.3
The sensor is connected to the controller by the sensor cable. The connection is made by simple plugging.
The connector locks automatically. The tight fit can be checked by pulling the connector housing (cable
bushing). The lock can be released and the connector can be opened by pulling the knurled housing sleeve
of the cable bushing.
capaNCDT 6200
Thickness 0.9
2.9
4.2 (0.17)
(0.11)
4.5
(0.18)
CSG1,00-CAm2,0
ensor Cable
S
-0.05 (0.04 -0.002 ) Sensor structures
200 (7.87)
216 (8.5)
3.85
(0.15)
9.9 (0.39)
1 (0.04)
Page 29
