Sensor Cable - MICRO-EPSILON capaNCDT 6200 Operating Instructions Manual

Functional Principle, Technical Data
2.2.2
Sensor and controller are connected by a special, double screened sensor cable.
Do not shorten or lengthen these special cables.
Usually, a damaged cable can not be repaired.
Switch off the device when plugging and removing connectors.
Do not crush the sensor cable.
Do not modify to the sensor cable.
> Lost of functionality
Model
CCgxC
CCgxC/90
CCgxB
CCgxB/90
CCmxC
CCmxC/90
CCmxB
CCmxB/90
The sensors of type CSH have integrated a 1.4 long sensor cable. Cable lengths of 2.8 m are available too if
required.
Other cable lengths are also available on request.
The sensor model CSE1 (measuring range 1 mm) has the connector type C.
capaNCDT 6200

Sensor Cable

Cable length Cable ø
2/4 or 6 m 3.1 mm
2/4 or 6 m 3.1 mm
2/4 or 6 m 3.1 mm
2/4 or 6 m 3.1 mm
1.4/2.8 or 4.2 m 2.1 mm
1.4/2.8 or 4.2 m 2.1 mm
1.4/2.8 or 4.2 m 2.1 mm
1.4/2.8 or 4.2 m 2.1 mm
2 axial 1x axial For sensors
connector + 1x 90
0
• 0.05 - 0.8 mm
• 0.05 - 0.8 mm
• 1 ... 10 mm
• 1 ... 10 mm
• 0.05 - 0.8 mm
• 0.05 - 0.8 mm
• 1 ... 10 mm
• 1 ... 10 mm
Min. bending radius
once permanently
10 mm 22 mm
7 mm 15 mm
Page 14
