Appendix| EtherCAT Documentation
Object 6020h: Measuring values
6020
Subindices
0
3
8
9
10
11
A 6.3
The measuring values are transmitted as Float.
The unit can be read from the channel info objects 2020h to 2023h (unit).
capaNCDT 6200
RECORD Measuring values
VAR Number of entries
VAR Counter
VAR Channel 1
VAR Channel 2
VAR Channel 3
VAR Channel 4

Measurement Data Format

11 Unsigned8
xxxx Unsigned32
xxxx Float
xxxx Float
xxxx Float
xxxx Float
ro
ro
ro
ro
ro
ro
ro
Page 107
