Functional Principle, Technical Data
2.2.1
For this measurement system, several sensors can be used.
The capacitive measuring process is area-related. A minimum area (see table) is required depending on the
sensor model and measuring range. In the case of insulators the dielectric constant and the target thickness
also play an important role.
Sensors for electrical conducting targets (metals)
capaNCDT 6200

Sensors

In order to obtain accurate measuring results, keep the surface of the sensor clean and free from dam-
age.
Sensor model Measuring range
CS005
CS02
CSH02
CSH02FL
CS05
CSE05
CSH05
CSH05FL
CS08
CS1
CSE1
CSH1
CSH1FL
CS1HP
CSH1,2
CSH1.FL
Min. target diameter
0.05 mm
0.2 mm
0.2 mm
0.2 mm
0.5 mm
0.5 mm
0.5 mm
0.5 mm
0.8 mm
1 mm
1 mm
1 mm
1 mm
1 mm
1.2 mm
1.2 mm
3 mm
5 mm
7 mm
7 mm
7 mm
6 mm
7 mm
7 mm
9 mm
9 mm
8 mm
11 mm
11 mm
9 mm
11 mm
11 mm
