MICRO-EPSILON capaNCDT 6200 Operating Instructions Manual page 51

Ethernet Interface
By default, the IP address of the controller is set to 169.254.168.150. Communication with the controller is
done on the data port 10001 for measurement transmission. A command port (Telnet, port 23) is used for
sensor commands.
The IP settings and the data port can be changed at any time:
- by using the web browser. Enter the current IP address into the address bar. Go to the menu
- by using software commands, see Chap. 6.4.
- by using the
If you activate DHCP , access to the controller via a DHCP host name is possible. The host name contains the
device name and serial number. Structure: NAME_SN e. g. DT6220_1001.
capaNCDT 6200
> Digital Interfaces > Ethernet settings
change the data port.
SensorFinder
software.
to set a new IP address, activate DHCP or
Settings
Page 51
