Appendix| EtherCAT Documentation
Object 2020h: Channel information
2020
Subindices
0
1
2
5
7
8
16
The structure of objects 2021h to 2027h corresponds to the object 2020h.
Object 2060h: Controller settings
2060
Subindices
0
1
2
3
4
5
capaNCDT 6200
RECORD Channel 1 info
VAR Number of entries
VAR Name
VAR Serial No
VAR Status
VAR Range
VAR Unit
VAR Linearization
RECORD Controller Settings
VAR Number of entries
VAR Sample rate
VAR Averaging type
VAR Averaging number
VAR Trigger
VAR Analog Lowpass
16 Unsigned8
DL6230 Visible String
xxxxxxxx Unsigned32
Active Enum
100 Unsigned32
µm Enum
Off Enum
5 Unsigned8
2083.3 Hz Enum
Off Enum
2 Enum
Off Enum
Inactive Enum
ro
ro
ro
ro
ro
rw
ro
ro
ro
ro
rw
rw
rw
rw
rw
