ci5000 Series Printer Technical Service Manual
Next Select the Barcode size. Please note the max selection will always be the maximum pixel size of
the message. See below.
Note: adding Human Readable text below the barcode requires using the "Alphanumeric Display" shown
on screen 2 to be changed to "Yes". (See below)

Graphic

Graphics/Bitmaps can be inserted into messages and printed. These need to be created in as a
Monochrome Bitmaps. This can be easily done using Microsoft Paint. For more information on how to
create graphics using Microsoft Paint see below.
Inserting a Graphic into a message:
Press the [Add Field] button and select Graphic from the options list and press the [Save]
button.
Version 0.1 3-45
