o If any System Property is changed that may affect the message.
o If the Print Adjust screen is used to change certain Properties.
Acknowledgement Complete
Acknowledgement Complete will transmit to an external computer that a print buffer has completed
printing. This Acknowledgement has an option to transmit a single character "C," or to transmit the text
from every field in the message. The "C" is transmitted by itself; the field data will end with a <CR>.
The field data is transmitted as comma-delimited fields, plus two additional fields for date and time
stamps. This data can be placed into a log as a record of every message printed. The field data is built
up as the fields are processed in the message; the fields will appear in the order that they were added to
the message, not in the order that they appear in the message.
Acknowledgement Photocell
The Acknowledgement Photocell will transmit to an external computer whenever the Photocell Trigger is
sensed. This Acknowledgement will transmit a single character "P."
The Acknowledgement Photocell will be transmitted at every Photocell Trigger, whether the Jet is on or
off, and whether the Printer is ready to print or not.

Web Browser Utility

The 5000 Series printer uses the web browser as a method to update the printer's firmware,
perform Backup and Restore, download graphics, fonts and language files without the need of
other programs.
Using the printer's Ethernet connection port on the CPU board for this process. A standard
Ethernet cable can be used when connecting thru a hub, switch, or router. An Ethernet
Crossover Cable must be used when connecting directly from a computer to the printer.
Open a web browser and type in the IP address assigned and entered into the printer. (example
http://192.168.1.250)
The browser will display a dropdown menu (as shown below)
