3. Set the Modulation to 170 by pressing the [Edit]
170 from the list and press the [Save]
NOTE: there are multiple screens. Use the up and down arrows to scroll thru the screens to find
the setting.
4. Using the [Edit]
. Take a print sample by pressing the [Print Trigger]
Bar on the right edge of the screen. (The Bands range is from -10 to +10)
Advance the Band by 1, wait 5 seconds, then take a print sample after each adjustment.
(Use both + and –ranges).
o Inspect each sample at each Band setting for print defects and select the best print
quality band to make your final set point.
NOTE: Multiple good bands are possible to be found.
Version 0.1
Button to the right of Band, select Band 0 from the list and press [Save]
ci5000 Series Printer Technical Service Manual
button to the right of Modulation. Select
button.
button in the Function Tool
