ci5000 Series Printer Technical Service Manual
Valves can be tested by pressing the [Menu] tab on the Main screen and then press [Service]
. Press the [Test Valves] button in the Navigational Tool Bars. Pressing/selecting a valve
while in this screen will activate the valve. Pressing/Selecting the "No Valve" or a different valve will
deactivate the valve. This will allow the user to test the operation of each valve.
NOTE: The [Test Valve] screen cannot be selected while the jet is on.
Version 0.1 1-25
