There can be multiple Customer files on 1 USB if installed onto multiple printers. This allows multiple
printer files to be stored onto 1 USB
(SYSTEM File)
Upgrading Firmware:
1. Insert the USB into a printer and have the File Structure installed (as mentioned above).
2. Remove the USB from the printer and insert into any PC.
3. Navigate to the USB, open the System File Folder, then open the Firmware Folder
4. From the PC, copy and then paste the newest firmware into the Firmware folder on the USB.
5. Close and remove the USB from the PC and plug into the USB port on the CPU Board
6. Press in sequence, the [Menu dropdown]
to the file screen.
7. Select the USB by pressing the letters USB on the left of the screen.
8. A screen will display "Initializing", and after a few seconds the USB will be highlighted and the
file structure displayed
9. In the File Menu screen, Press the [Plus]
folder
10. Next open the "Firmware" folder by pressing the [Plus]
11. Next Highlight the actual file and then press the [Install Firmware]
Bar to download the firmware to the printer
12. There will be a confirmation screen displayed to confirm (Yes or No) if you want to proceed and
install the firmware. Selecting Yes and this will start the upgrade
13. There will then be a screen displaying "Installing" while the firmware is downloading
14. This will take approximately 30 seconds
15. When the download is complete, the printer will automatically close the screens to the Home
screen and then reboot.
16. When the printer reboots, note the firmware has been upgraded in the bottom right of the screen.
Install Fonts:
The 5000 Series has now a large enough memory that ALL Fonts, Languages, and Keyboard IME's will
be installed on the printers before they leave Citronix, however if any are removed or otherwise need to
be installed the following will give these instructions.
Version 0.1
ci5000 Series Printer Technical Service Manual
,[Properties] ,[File]
symbol next to the "System" folder to open the
symbol
buttons to navigate
button in the Function Tool
