Drop Size; Print Quality (Ciprecisionplus); Delay - Citronix ci5200 Technical & Service Manual

for each message. This allows different messages to be used for different products or production lines at
different drop sized (depending on the printer type), delays, Print Quality, etc.....
The Print Adjust Parameters are:
1.

Drop Size

2. Print Quality
3.

Delay

4. Width
5. Gap
6. Orientation
7. Bold
8. Height
9. Auto Print Pitch
From the Main screen, press the [Print Adjust]
The following 2 screen are available to be adjust "on the fly" or while the printer is printing on line.
Drop Size
The drop size changes the size of the printed drop. This can make the print look darker or bolder;
however the drop size can/will affect the speed that can be printed. The following is a chart of the Drop
Sizes allowed by printer type.
Version 0.1
ci5000 Series Printer Technical Service Manual
button located in the Navigation Tool Bar.
3-63
