Level 2 (Service Engineers) Spares

Part Number
100-0011-004a
004-1002-001
004-1029-001
004-1001-003
004-2012-002
003-1005-001
003-1006-001
003-1023-001
003-1024-001
002-1073-002
003-1025-001
002-2002-003
002-1012-003
002-2005-002
014-1032-001
014-1051-001
014-1078-001
014-1067-001
014-1066-001
014-1074-001
014-1075-001
014-1080-001
014-1052-001
014-1076-001
014-1040-001
014-1085-001

Tools

Version 0.1
Description
PCB, CPU Tested (Rev 4)
**Specify machine type at ordering
PSU, High Voltage
Power Supply, DC
Fan, Cooling
Display Assy, w/ LED Backlight, Qtr VGA
Pump, Head
Pump, Motor
Valve, Ink Manifold 2 Way
Valve, Ink Manifold 3 Way
PCB, Phase Amp/Sensor Assy
Valve, PH 3 way
Assy, Drop Generator 2008
Plate, Deflector GND
Assy, Deflector Plate Angled +
Loupe, Eye Piece
Wrench, Allen Key 1/16 inch
Wrench, Allen Key 1/32 inch
Wrench, Allen Key 3/16 inch
Wrench, Allen Key 5/32 inch
Screwdriver, Slotted 1/8 inch
Screwdriver, Phillips #0
Cutter, Side Cutters
Cutter, Tubing
Flashlight, Service
Pliers, Flat Nose
Wrist Strap, ESD
Part Number
Description
