ci5000 Series Printer Technical Service Manual
Press the [OK] button. The next screen will ask you to scan a new bottle. Do this by holding a bottle up to
the ciSafeFill icon on the touch screen so the two (2) ciSafeFill symbols match for approximately 2
seconds. The screen will read and verify the fluids and give you further instructions once the scan is
complete.
Once the fluid is verified, remove/open the Ink (black) or Makeup (yellow) fill capon top of the printer. Do
NOT remove the foil seal.
Insert the Ink or Makeup bottle in the proper fill port and rotate clockwise by 90° to lock it in place.
Makeup bottle inserted in fill port Ink bottle inserted in fill port
Version 0.1 3-68
