4. Mirror Down

Bold

Bold defines the number of times that every printed raster (vertical stroke) is repeated. Each bold
increment increases the overall length of the print. To select a bold value, press the [Edit]
the right of the bold valve. Select the desired setting from the list (between 0 and 9) then press [Select]
.
NOTE: The higher the bold setting the slower the print speed. For example; a bold
setting of 3 will print slower speed than a bold setting of 1 or 0.

Height

The Height setting defines the overall height of the message. To adjust the Height setting, press the [Edit]
button to the right of the Height valve. Adjust using the numbers keypad enter the desired setting
(between 50 and 255) then press [Save]
NOTE: Setting the height too low can cause the print to clip the gutter block. This
causes the printhead to also get dirty. Setting too high can also result in a dirty
printhead and multiple HV Faults. An average setting of 200 works best.

AutoPrint Pitch

AutoPrint Pitch defines a fixed amount of time/space from the beginning of one message to the
beginning of the next when in AutoPrint mode. To adjust the AutoPrint Pitch setting, press the [Edit]
button to the right of the AutoPrint Pitch valve. Adjust using the numbers keypad enter the desired setting
(between 0 and 2147483647) then press [Save]

Repeat Printing

The current message can be repeated for a specified number of extra prints for one product detect signal.
Note: The number of counted repeats is extra to the initial print.
Example: 6 will print 7 times total.
To setup Repeat Printing:
Create a new message or Edit an existing message as described in the above sections.
