6. After 10 seconds, press the Cancel button in the function Tool Bar to stop the process.
7. In the unlikely event this does not resolve the problem, repeat the process up to 10 times. If the
problem persists, contact a maintenance technician.

Replace/Clean Air Filter:

Depending on the environment the printer is operating, it may be necessary to clean or replace the air
filter on a regular interval.
The Air Filter is located on the right-hand side of the cabinet. To clean or replace the Air Filter:
1. Remove the Air Filter (yellow cover together with the filter element).
2. Remove the filter element by unclipping or unsnapping the filter element. Tilt or twist the yellow
cover to release one side of the handle then twist in the opposite direction to release the second
side as shown below.
Version 0.1
ci5000 Series Printer Technical Service Manual
Spray Cleaning Solvent into Nozzle
Filter element
6-13
