NOTE: If the pump is intended to be re-used, make sure the pump is cleaned using the
appropriate Cleaning Solvent for the Ink type being used. Failure to do so will result in the Ink
drying in the pump gears and causing damage.

Changing / Cleaning an Ink System Valve and Gasket

1. Remove the Ink system housing cover.
2. Remove the Solenoid from the valve stem by removing the plastic hold-down clip on the end of the
Solenoid and removing from the valve.
3. Remove the two screws securing the valve to the Ink manifold. Remove the valve from the
manifold, taking care not to lose the valve gasket. Flush the valve with solvent to prevent Ink from
drying in it.
4. Replace the cleaned valve, replacement valve, or replacement gasket.
NOTE: If the valve is intended to be re-used, make sure it is cleaned using the appropriate
Cleaning Solvent for the Ink type being used. Failure to do so will result in the Ink drying in the
valve, causing damage.
