Unocode 399 PLUS
1.4 T
ECHNICAL
Electricity supply:
230V-50Hz
Nominal power:
230V: 1,1 Amp. 210 Watt
cutter motor:
single phase and speed
cutter:
hard metal
Tool speed:
50Hz: 1700 rpm (+/- 10%)
Movements:
on 2 axes with ball screws activated by step motors, on rectified roller guides.
Possibility to add a 3rd axis to activate the optional tilting and rotating clamps.
Clamp:
universal 4 sided clamp to grip flat, car and cruciform keys
Runs:
X axis: 57 mm
Dimensions:
width: 500 mm depth: 700 mm height: 700 mm (with raised shield 900 mm)
Mass:
Kg. 51
Noise level:
sound pressure Lp(A) =
8
D
ATA
Y axis:: 32 mm
80 dB(A) (cutting iron keys)
77 dB(A) (cutting brass keys)
