Unocode 399 PLUS
5.11.4 CODEMAKER
• Appears when the depth value exceeds the key blank measurement assigned to the key.
• Appears when the set angle is higher or lower than the limit allowed by the cutter in use.
• Appears when the set depth is higher or lower than the limit for the clamp in use.
• Appears when the value of a set space is not within the limit.
• Appears when the value of a set flare is not within the limits.
• The set combination of spaces and flares exceeds the maximum run allowed for the space axis.
• Appears when the value of a set flare would overlay a previous flare.
• Appears when the value of a space is altered in such a way as to cause the flare to overlay the previous one.
60
MESSAGES
Key Blank dimension
out of range!
Limit values:
Cutting angle out of range!
Limit values:
Cutting Depth out of range!
Limit values:
Spacing value out of range!
Base of cut out of range!
Limit values:
Cutting process exceeds
X axis carriage range !
See operating manual.
Overlapping base of cut!
Spacing values
are not compatible
with base of cuts!
The cut depth is not
compatible with cutting
edge of the cutter.
See operating manual.
