Silca Unocode 399 Plus Operating Manual page 55

Operating manual - English
C2
Figura 39
ATTENTION: if it is necessary to
work close to this area with the
machine turned on (e.g. to regulate
the X axis sensor) take great care not
to touch any components on the
machine's electronic boards as it is
connected to 230 Volts.
Figura 40
Fig. 41
bottomview
X axis sensor
C3
Copyright Silca 2016
Unocode 399 PLUS
Y axis sensor
C1
C2
C3
51
