Technical Data - Silca Quattrocode Operating Manual

QUATTROCODE
1.3

Technical data

POWER SUPPLY:
MAX. ABSORBED POWER:
CUTTER MOTOR:
CUTTING TOOLS:
CUTTER SPEED:
MOVEMENTS:
CLAMP:
RUNS:
DIMENSIONS:
MASS:
NOISE RATING:
Personal Computer
The personal computer (not included) to be used for transmission of the operating program to the
Quattrocode should have the following minimum specifications:
- Model: IBM
- Operating system: MS-DOS version 3.30 or later
- RAM: minimum 640 Kb
- Floppy disk unit: 1 x 1.2 Mega (5
- Minimum hard disk capacity: 5 MB
- Serial port: RS-232
- Parallel port (printer): Standard
- Video screen: VGA Monochrome
A Pentium 90Mhz microprocessor is preferable
- Version MS-DOS 6.0
- Video VGA-Colour (High Resolution Graphics)
N.B.: proper operation of the program and data transmission from the personal computer to
the Quattrocode key-cutting machine cannot be guaranteed unless the personal computer
'BIOS' is 100% IBM compatible.
Accessories provided
Quattrocode is provided with a set of accessories for use and maintenance of the machine (tools,
hex. wrenches, fuses, etc.), found in the tool box provided.
Tool box
13 mm wrench
10 mm wrench
7-8 mm wrench
1.5 mm allen wrench
5 mm allen wrench
6 mm allen wrench
Elbowed wrench
Straight brush
Single phase 220V (110V - 60 Hz)
1.5 Amp (350 W) (110V: 3 Amp (350W)(
Two-speed single phase
in HSS (high speed steel) or Widia (hard metal)
6000 rpm (+/- 10%) (HSS) / 12000 rpm (+/- 10%) W
(hard metal)
On three axes with preloaded recirculating ball screws
activated by step motors on ground roller guides.
Cutting tool spindle released and locked by a step motor.
Universal 'J1' (standard) for key lock grip, reversible
mobile jaw for locking special 'Z' profile Mercedes keys.
X axis: 55 mm
Y axis: 55 mm
Z axis: 55 mm
Width 390 mm / depth 530 mm / height 570 mm
60 kg.
Noise pressure: Lp (A) = 79.16 dB (A)
1
or 100% IBM compatible - Microprocessor 80286 at 12 Mhz or over.
Locking bar
Gauging template and pin
A - 4 Amp. fuse - rapid
B - 1 Amp. fuse - delayed
C - D - E - 4 Amp. fuse- delayed
F - 1.6 Amp. fuse - delayed
G - 3.15 Amp. fuse - rapid
3 m serial cable 25/9 pin
Jumper cable
Copyright Silca 1999
Operating manual - English
Screwdriver handle
2 mm socket head
2.5 mm socket head
3 mm socket head
4 mm socket head
Flat screwdriver
Star screwdriver
