Unocode 399 PLUS
5.8

MAINTENANCE

From the initial screen press MENU then F2 to enable the function.
Use the up/down arrow keys to select the option and
press ENTER, or directly press the key relating to
the option number.
5.8.1

MOTOR TESTS

Read the instructions on the display carefully and
check that the carriage (or optional clamp in the
case of B) for the axis involved moves.
ATTENTION:
are disactivated; avoid moving the carriage up against its
mechanical stops.
5.8.2

DIGITAL INLETS TEST

- Lift and lower the protective shield checking that the ma-
chine's display indicates OFF (with shield raised) to ON (with
shield lowered).
Note: if the ON/OFF transition is not made, contact Silca's
Technical Assistance Dept.
Jaw acknowledgement: operational only with
electrically connected device.
This test can be carried out only when an automatic feeder (or
other optional component) is installed on the machine.
44
during this test function all end of run controls
