Operating manual - English
7.13 WIN-TRANSFER P
The machine is supplied with an internal program already loaded and tested in our workshops. The
user therefore does not need to carry out any operations.
Only in the situations described below can the WIN-TRANSFER program be used to re-start the
machine.
The following is a list of situations where the use of the WIN-TRANSFER program is required.
• Replacement of the electronic board (see chap. 7.6, page 68) or loss of the
internal machine program.
1) replace the board with a new one, if necessary.
2) install on your personal computer the latest version received of the WinTransfer program.
3) read the serial number on the data plate on the back of the machine (ch.5.9, page 52) and enter on the machine.
4) gauge the machine according to the instructions in the manual, as follows:
- gauge as explained in chapter 5.8.7 "MACHINE ZERO POINTS" and chap.5.7.1 "Calibrate STANDARD JAWS"" in
the user's manual.
- first gauge the V100 clamp (chap. 5.7.1, page 41).
- continue with the gauging of remaining jaws used.
At this point the machine is set up and ready for operation.
• SILCA update for the program or machine data
1) Install the WinTransfer Program update on your personal computer, following the instructions in the
program.
/
ROGRAM FOR LOADING UPDATING THE INTERNAL MACHINE PROGRAM
Copyright Silca 2016
Unocode 399 PLUS
75
