5.3.2

ACCESSORY FUNCTIONS FOR "COPY BY DATA CARD"

a) Data Card Decoding
FUNCTION NOT AVAILABLE ON THIS MACHINE
b) Manual Adjustments
• Press F2 to set manual adjustment to cutting depths
and spaces.
Figura 26
• Press F1 to obtain positive values (+).
• Press F2 to obtain negative values (-).
• Press F3 to cancel the settings.
Y depth adjustment (from -30 to +30 hundredths
of a mm):
- Y positive value: raise the cuts
- Y negative value: lower the cuts
X space adjustment (from -30 to +30 hundredths
of a mm):
- X positive value: move cuts to the right of the stop
- X negative value: move cuts to the left of the stop
This symbol appears in Copy by
Data Card when manual adjustments have been made.
F1
F2
cutting angle
cutting spaces
flare (base of the cut)
F1
F2
F3
Copyright Silca 2016
Unocode 399 PLUS
cutting
depths
25
