Touch Probe Cycles: Automatic Kinematics Measurement | PRESET COMPENSATION (Cycle 452, DIN/
Insert the second interchangeable head
Insert the touch probe
Measure the interchangeable head with Cycle 452
Measure only the axes that have actually been changed (in this
example: only the A axis; the C axis is hidden with Q422)
The preset and the position of the calibration sphere must not be
changed during the complete process
All other interchangeable heads can be adjusted in the same way
The head change function can vary depending on the
individual machine tool. Refer to your machine manual.
706
Adjusting an interchangeable head
3 TOOL CALL "TCH PROBE" Z
4 TCH PROBE 452 PRESET
COMPENSATION
Q407=12.5 ;SPHERE RADIUS
Q320=0 ;SET-UP CLEARANCE
Q408=0 ;RETR. HEIGHT
Q253=2000 ;F PRE-POSITIONING
Q380=+45 ;REFERENCE ANGLE
Q411=-90 ;START ANGLE A AXIS
Q412=+90 ;END ANGLE A AXIS
Q413=45 ;INCID. ANGLE A AXIS
Q414=4 ;MEAS. POINTS A AXIS
Q415=-90 ;START ANGLE B AXIS
Q416=+90 ;END ANGLE B AXIS
Q417=0 ;INCID. ANGLE B AXIS
Q418=2 ;MEAS. POINTS B AXIS
Q419=+90 ;START ANGLE C AXIS
Q420=+270 ;END ANGLE C AXIS
Q421=0 ;INCID. ANGLE C AXIS
Q422=0 ;MEAS. POINTS C AXIS
Q423=4 ;NO. OF PROBE POINTS
Q432=0 ;BACKLASH, ANG. RANGE
HEIDENHAIN | User's manual for cycle programming | 10/2017
ISO: G452, option)
