2.4

Inverter Connector

J3 : Inverter Connector
The pin assignment is as follows:
PIN
ASSIGNMENT
1
+12V
2
GND
3
VCC
4
NC
5
ENABKL (Inverter backlight
ON/OFF control signal)
14
®
®
SBC81870 Intel
Pentium
Hardware Configuration
M w/ DDR/VGA/Dual LAN
