4.6

Integrated Peripherals

Choose〝INTEGRATED PERIPHERALS〞from the main setup
menu, a display will be shown on screen as below:
Phoenix - AwardBIOS CMOS Setup Utility
OnChip IDE Device
Onboard Device
SuperIO Device
Watch Dog Timer Select
↑↓→←: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit
F5: Previous Values
F1:General Help
F7:Optimized Defaults
Integrated Peripherals Setup Screen
By moving the cursor to the desired selection and by pressing
the <F1> key, the all options for the desired selection will be
displayed for choice.
If bios setup menu item supports USB device boot, it will
cause Win9x detects the same storages twice when the
system is rebooted, and USB HDD will fail.
Note: this cause just happen under Win9x, the phenomenon is
a limitation.
66
®
SBC81870 Intel Pentium
Integrated Peripherals
[Press Enter]
[Press Enter]
[Press Enter]
[Disabled]
F6: Fail-Safe Defaults
®
M w/ DDR/VGA/Dual LAN
Item Help
►
Menu Level
Award BIOS Setup
