If you want to save up the original BIOS, enter "Y" and
press < Enter >. If you choose "N", the following table
will appear on screen.
FLASH MEMORY WRITER v7.XX
(C) Award Software 2001 All Rights Reserved
Flash Type – SST 49LF004A /3.3V
File Name to Program: H20bxxxx.bin
Error Message : Are You Sure To Program (Y/N)
Select "Y", and the BIOS will be renewed. When you are
refreshing the BIOS, do not turn off or reset the system,
or you will damage the BIOS. After you have completed
all the programming, the screen displays the table below:
FLASH MEMORY WRITER v7.XX
(C) Award Software 2001 All Rights Reserved
Flash Type – SST 49LF004A /3.3V
File Name to Program: H20bxxxx.bin
Reset System or Power off to accomplish update process!
Please reset or power off the system, and then the Flash
BIOS is fully implemented.
44
® ®
SBC81870 Intel Pentium
Checksum: XXXXX
Checksum: XXXXX
F1: Reset F10: Exit
M w/ DDR/VGA/Dual LAN
Software Utilities
