AXIOMTEK SBC81870 Series User Manual page 80

® ®
SBC81870 Intel Pentium M w/ DDR/VGA/Dual LAN
SOFT-OFF BY PWR-BTTN:
Pressing the power button for more than 4 seconds forces the
system to enter the Soft-Off state when the system has "hung".
The choices are Delay 4 Sec and Instant-Off.
RESUME BY ALARM:
When Enabled, your can set the date and time at which the
RTC (real-time clock) alarm awakens the system from Suspend
mode.
PM EVENTS:
PM events are I/O events whose occurrence can prevent the
system from entering a power saving mode or can awaken the
system from such a mode. In effect, the system remains alert
for anything, which occurs to a device which is configured as
Enabled, even when the system is in a power down mode. (1)
Primary IDE 0 (2) Primary IDE 1 (3) Secondary IDE 0 (4)
Secondary IDE 1 (5) FDD, COM, LPT Port
74
Award BIOS Setup
