1.1

About This Manual

Thank you for purchasing our SBC81870 Socket 478 Pentium
M Full Size Card enhanced with DDR/VGA/ Dual LAN, which is
fully PC / AT compatible. SBC81870 provides faster processing
speed, greater expandability and can handle more task than
before. This manual is designed to assist you how to install
and set up the system. It contains four chapters. The user can
apply this manual for configuration according to the following
chapters.
Chapter 1 Introduction
This chapter introduces you to the background of this
manual, and the specification for this system. Final part
of this chapter will indicate you how to avoid damaging
this Embedded Card.
Chapter 2 Hardware Configuration
This chapter outlines the component location and their
functions. In the end of this chapter, you will learn how
to set jumper and how to configure this card to meet your
own needs.
2
® ®
SBC81870 Intel Pentium M w/ DDR/VGA/Dual LAN
