Trouble Shooting For Error Messages
The following information gives you the error messages and the
trouble- shooting. Please adjust your systems according to the
messages below. And make sure all the components and
connectors are in proper position and firmly attached. If the
errors still encountered, please contact with your distributor for
maintenance.
Post Beep:
Currently there are two kinds of beep codes in BIOS. One code
indicates that a video error has occurred and the BIOS cannot
initialize the video screen to display any additional information.
This beep code consists of a single long beep followed by two
short beeps. The other code indicates that your DRAM error
has occurred. This beep code consists of a single long beep
repeatedly.
CMOS Battery Has Failed:
This message informs you that the CMOS battery is no
longer functional. The user should replace it.
CMOS CHECKSUM ERROR:
This message informs you that the CMOS is incorrect. This
error may have caused by a weak battery. Check the battery
and replace if necessary.
Disk Boot Failure, Insert System Disk And Press Enter:
No boot device was found. This could mean that either a
boot drive was not detected or the drive does not contain
proper system boot files. Insert a system disk into Drive A:
and press < Enter >. If you assumed the system would boot
from the hard drive, make sure the controller is inserted
correctly and all cables are properly attached. Also make
sure the disk is formatted as a boot device. Then reboot the
system.
Diskette Drives Or Types Mismatch Error - Run Setup:
Type of diskette drive installed in the system is different from
the CMOS definition. Run Setup to reconfigure the drive type
correctly.
