Memory Installation

SBC8170 CPU Card can support up to 2GB in two DIMM
sockets.
DRAM BANK CONFIGURATION
DIMM 1 DIMM 2
128MB 128MB
256MB 256MB
512MB 512MB
1GB
If want to install two DIMMs, please make sure both of
memories are exactly the same brand and same model.
Hardware Configuration
®
SBC81870 Intel Pentium
TOTAL MEMORY
256MB
512GB
1GB
1GB 2GB
®
M w/ DDR/VGA/Dual LAN
33
