SBC81870 Intel Pentium M w/ DDR/VGA/Dual LAN
Memory Verify Error At ... :
Indicates an error verifying a value already written to memory.
Use the location along with your system's memory map to
locate the bad chip.
Offending Address Not Found:
This message is used in conjunction with the I/O CHANNEL
CHECK and RAM PARITY ERROR messages when the
segment that has caused the problem cannot be isolated.
Offending Segment:
This message is used in conjunction with the I/O CHANNEL
CHECK and RAM PARITY ERROR messages when the
segment that has caused the problem has been isolated.
Press A Key To Reboot:
This will be displayed at the bottom screen when an error
occurs that requires you to reboot. Press any key and the
system will reboot.
Press F1 To Disable Nmi, F2 To Reboot:
When BIOS detects a Non-maskable Interrupt condition during
boot, this will allow you to disable the NMI and continue to boot,
or you can reboot the system with the NMI enabled.
Ram Parity Error – Checking For Segment:
Indicates a parity error in Random Access Memory.
Should be Empty But EISA Board Found
Please Run Eisa Configuration Utility:
A valid board ID was found in a slot that was configured as
having no board ID.
Note: When this error appears, the system will boot in ISA
mode, which allows you to run the EISA Configuration Utility.
Should Have EISA Board But Not Found
Please Run Eisa Configuration Utility:
The board installed is not responding to the ID request, or no
board ID has been found in the indicated slot.
Note: When this error appears, the system will boot in ISA
mode, which allows you to run the EISA Configuration Utility.
100
Trouble Shooting
