AXIOMTEK SBC81870 Series User Manual page 82

RESOURCE CONTROLLED BY:
The Award Plug and Play Bios can automatically configure all
of the booth and Plug and Play-compatible devices. However,
this capability means absolutely nothing unless you are using a
Plug and Play operating system such as Windows 95. By
choosing "manual", you are allowed to configure the IRQ
Resources and DMA Resources.
IRQ RESOURCES:
The options for these items are found in its sub menu. By
pressing the <ENTER> key, you are prompt to enter the sub
menu of the detailed options as shown below:
Phoenix – Award CMOS Setup Utility
IRQ-3 assigned to
IRQ-4 assigned to
IRQ-5 assigned to
IRQ-7 assigned to
IRQ-9 assigned to
IRQ-10 assigned to
IRQ-11 assigned to
IRQ-12 assigned to
IRQ-14 assigned to
IRQ-15 assigned to
↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit
F5: Previous Values
F1:General Help
F7:Optimized Defaults
Descriptions on each item above are as follows:
76
®
SBC81870 Intel Pentium
IRQ Resources
[PCI Device]
[PCI Device]
[PCI Device]
[PCI Device]
[PCI Device]
[PCI Device]
[PCI Device]
[PCI Device]
[PCI Device]
[PCI Device]
F6:Fail-Safe Defaults
®
M w/ DDR/VGA/Dual LAN
Item Help
Menu Level ►
Legacy ISA for devices
compliant with the
original PC AT bus
specification, PCI/ISA
PnP for devices
compliant with the Plug
and Play standard
whether designed for
PCI or ISA bus
architecture
Award BIOS Setup
