AXIOMTEK SBC81870 Series User Manual page 75

2. USB Keyboard Support
Select Enabled if your system contains a Universal Serial
Bus (USB) controller and you have a USB keyboard.
3. USB Mouse Support
Select Enabled if your system contains a Universal Serial
Bus (USB) controller and you have a USB Mouse.
4. AC97 Audio:
This item allows you to enable/disable to support AC97
Audio.
5. Init Display First
This item allows you to decide to active whether PCI Slot or
on-chip VGA first.
SUPER IO DEVICE:
The options for these items are found in its sub menu. By
pressing the <ENTER> key, you are prompt to enter the sub
menu of the detailed options as shown below:
Phoenix – Award CMOS Setup Utility
Onboard FDC Controller
Onboard Serial Port 1
Onboard Serial Port 2
UART Mode Select
X RxD, TxD Active
X IR Transmission Delay
X UR2 Duplex Mode
X Use IR Pins
Onboard Parallel Port
Parallel Port Mode
X EPP Mode Select
X ECP Mode Use DMA
PWRON After PWR-Fail
↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit
F5: Previous Values
F1:General Help
F7:Optimized Defaults
Award BIOS Setup
® ®
SBC81870 Intel Pentium
SuperIO Device
[Enabled]
[3F8/IRQ4]
[2F8/IRQ3]
[Normal]
Hi, Lo
Enabled
Half
IR-Rx2Tx2
[378/IRQ7]
[SPP]
EPP1.7
3
[Off]
F6:Fail-Safe Defaults
M w/ DDR/VGA/Dual LAN
Item Help
Menu Level ►
69
