Descriptions on each item above are as follows:
1. Onboard FDC Controller
Select Enabled if the system has a floppy disk controller
(FDC) installed on the system board and you wish to use it.
If you install and-in FDC or the system has no floppy drive,
select Disabled.
2. Onboard Serial Port 1/2
Select an address and corresponding interrupt for the first
and second serial ports.
3. UART Mode Select
This item allows you to select UART mode.
4. RxD, TxD Active
This item allows you to determine the active of RxD, TxD.
5. IR Transmission Delay
This item allows you to enable/disable IR transmission
delay.
6. UR2 Duplex Mode
This item allows you to select the IR half/full duplex
function.
7. Use IR Pins
This item allows you to select IR transmission routes, one
is RxD2m, TxD2 (COM Port) and the other is IR-Rx2Tx2
8. Onboard Parallel Port
This item allows you to determine access onboard parallel
port controller with which I/O address.
9. Parallel Port Mode
Select an operating mode for the onboard parallel (printer)
port. Select Normal, Compatible, or SPP unless you are
certain your hardware and software both support one of the
other available modes.
10. EPP Mode Select
Select EPP port type 1.7 or 1.9.
